Name: 6VDC 12VDC 24VDC Dc Gear Motor RF520 RF500 Pear Shape 115RPM GM48B
Brand: LINO
Price: 1 USD

Brand Name : LINO

Model Number : GM48B

Certification : ROHS

Place of Origin : ZHEJIANGNINGBO

MOQ : 1K

Price : The price ranges from 30 to 50 rmb per unit. The specific model requirements vary

Payment Terms : T/T

Supply Ability : 100,000 units per month

Delivery Time : 30work days

Packaging Details : Carton with pallet

VOLTAGE : 6VDC,12VDC,24VDC

Direction of rotation : CW, CCW

MOTOR : RF520,RF500 DC MOTOR

CLUTCH : CLUTCH available

Shaft : Customizable

Contact Now

DC GEAR MOTOR GM48B

Products' type:	DC geared motor
Model:	GM48B
Sort:	Pear shape DC geared motor
Typical applications:	Coffee machine, communications-equipment, ACU-RITE,induced garbage can, electronic lock, optical equipment, medical instrumentation, office equipment, household appliances,etc…





Weight	140g (approx)

MODEL	VOLTAGE	AT NO LOAD		AT MAXIMUM EFFICIENCY				AT STALL
	VOLTAGE	SPEED	CURRENT	SPEED	CURRENT	TORQUE		TORQUE		CURRENT
	VDC	RPM	A	RPM	A	mN.m	kg.cm	mN.m	kg.cm	A
GM48B2700-370	12	1.15	0.045	0.82	0.11	4478.6	45.700	15582	159.000	0.28
Base motor option	RF500,RS520,RS528,RF370
Gear ratio option	10, 26, 68.6, 114.5, 216, 235.6, 300, 617, 1031, 1944, 2700
Note	The specifications and output shaft can be changed as customer's request.
Packing detail	Carton, Size: 38X35.5X34CM;100pcs/carton; G.W:16Kg.
